| Pump name | PVDF Magnetic Drive Pump |
| Type | CQF |
| Model | 10CQF-3,14CQF-5, 16CQF-8, 20CQF-12, 25CQF-15, 32CQF-15, 32CQF-25, 40CQF-20, 50CQF-25, 50CQF-32, 65CQF-25, 65CQF-32. |
| Manufacturer | HAINA PUMPS CO.,LTD |
| Working Principle | Centrifugal, Self-priming, Vortex |
| Applications | Chemical Industry, Pharmacy, Acid Cleaning, Farm Chemicals,waste water treatment,etc. |
| Driver | Electric |
| Working Temperature | -20°C ~ 120°C |
| Type of connection | Flange, Thread, Quick coupled |
| Installation position | Horizontal，Vertical |
| Pump body | PVDF |
| Shaft seal: | Magnetic coupling |
| Power | 0.18KW ~ 90KW |
| Caliber: | 15mm ~ 150mm |
| Flow | 0.72m3/h ~ 200m3/h |
| Head | 1m ~ 125m |
| Pressure | 0.1 ~ 12.5bar |
| Product Features | CQF Product is mainly made of GFRPP/PP/PVDF/PTFE and all flow-through pump parts adopt injection mould with resistance to most organic and inorganic acid, alkali and salty solutions, applicable for being exposed outdoor with fine anticorrosive performance of stress corrosion cracking. GFRPP/PP/PVDF/PTFE Magnetic Drive Pump is a new type of pump that uses the working principle of permanent magnet coupling to transfer torque without contact. When the prime mover drives the outer magnetic steel to rotate, it drives the inner magnetic steel rotor to rotate synchronously through the action of the magnetic field, and the inner magnetic steel rotor and the impeller are connected into one, so as to achieve the purpose of driving the impeller to rotate without contact. Because of liquid sealed in the stillness of the isolation set inside, so the magnetic pump is a fully enclosed, without leakage of product, with static seal instead of dynamic seal, magnetic pump flow components of pump in a completely sealed state, conveying fluid leak-off, selection of magnetic pump corrosion, the steel ceramics, reinforced polypropylene as manufacturing material, so it has good corrosion resistance, And can make the real transport medium from pollution. |
PVDF Magnetic Drive Pump – White Pump
GFRPP/PP/PVDF/PTFE Magnetic Drive Pump is a new type of pump that uses the working principle of permanent magnet coupling to transfer torque without contact. When the prime mover drives the outer magnetic steel to rotate, it drives the inner magnetic steel rotor to rotate synchronously through the action of the magnetic field, and the inner magnetic steel rotor and the impeller are connected into one, so as to achieve the purpose of driving the impeller to rotate without contact.
