IHF Plastic lined Chemical centrifugal pump model

IHF Chemical centrifugal pump can transfer have corrosive liquid,China Haina pumps brand IHF centrifugal pump model as follow:

IHF Plastic lined Chemical centrifugal pump

No Model Speed

(r/min)

 Flow Head
(m)		 (%) Motor(KW) (NPSH)rm
m3/h L/S Shaft Motor
1 IHF25-20-125 2900 3.2 0.89 20 52 0.34 0.75 2.2
2 IHF25-15-250 2900 1.6 0.44 75 21 1.56 4 2.5
3 IHF40-25-140 2900 6.3 1.75 25 62 0.69 1.1 2.5
4 IHF40-25-250 2900 6.3 1.75 75 28 4.6 5.5 2.5
5 IHF50-40-125 2900 7.5 2.08 23 43 1.09 2.2 2
12.5 3.47 20 51 1.33 2.2 2
15 4.7 18 49 1.5 2.2 2.5
6 IHF50-40-125 1450 3.75 1.04 5.75 36 0.16 0.55
6.3 1.74 5 45 0.19 0.55 1
7.5 2.08 4.5 44 0.21 0.55
7 IHF50-40-160 2900 7.5 2.08 34.5 33 2.13 3 2
12.5 3.47 32 46 2.37 3 2
15 4.17 30 50 2.45 3 2.5
8 IHF50-40-160 1450 3.75 1.04 8.6 29 0.3 0.55 2
6.3 1.74 8 40 0.34 0.55 2
7.5 2.08 7.5 43 0.36 0.55 2.5
9 IHF50-40-200 2900 7.5 2.08 51.8 28 3.78 5.5 2
12.5 3.47 50 29 4.36 5.5 2
15 4.17 48 43 4.56 5.5 2.5
10 IHF50-40-200 1450 3.75 1.04 12.9 23 0.57 0.75
6.3 1.74 12.5 33 0.65 0.75 1
7.5 2.08 12 36 0.68 0.75
11 IHF50-40-250 2900 12.5 3.47 82 23 12.14 15 2
20 5.55 80 34 12.82 15 2.5
25 6.94 78.5 39 13.7 15 3.2
12 IHF50-40-250 1450 6.3 1.74 20.5 17 2.07 3
10 2.78 20 27 2.02 3 1
12.5 3.47 19.6 31 2.15 3
13 IHF65-50-125 2900 15 4.17 21.3 47 1.85 3
25 6.94 20 62 2.2 3 2
30 8.33 18.6 63 2.4 3
14 IHF65-50-125 1450 7.5 2.08 5.4 44 0.25 0.55
12.5 3.47 5 55 0.31 0.55 1.2
15 4.17 4.5 56 0.33 0.55
15 IHF65-50-160 2900 15 4.17 34.2 44 3.18 5.5 2
25 6.94 32 57 3.82 5.5 2
30 8.33 30 59 4.15 5.5 2.5
16 IHF65-50-160 1450 7.5 2.08 8.55 39 0.45 0.75
12.5 3.47 8 51 0.53 0.75 1.2
15 4.17 7.5 52.5 0.58 0.75
17 IHF65-50-200 2900 15 4.17 53.2 41 5.3 7.5 2
25 6.94 50 52 6.55 7.5 2
30 8.33 47.6 53.5 7.27 7.5 2.5
18 IHF65-50-200 1450 7.5 2.08 13.3 35 0.78 1.1
12.5 3.47 12.5 46 0.93 1.1 1.2
15 4.17 11.9 47.5 1.02 1.1
19 IHF80-65-125 2900 30 8.33 23.2 60 3.16 5.5 3
50 13.9 20 69 3.95 5.5 3
60 16.7 17.6 67 4.29 5.5 4
20 IHF80-65-125 1450 15 4.17 5.8 54 0.44 0.75 2.5
25 6.94 5 64 0.53 0.75 2.5
30 8.33 4.4 62 0.58 0.75 3
21 IHF80-65-160 2900 30 8.33 36 57 5.16 7.5 2
50 13.9 32 67 6.5 7.5 2.3
60 16.7 28.4 65 7.14 7.5 3.3
22 IHF80-65-160 1450 15 4.17 9 50 0.74 1.5
25 6.94 8 62 0.88 1.5 1.4
30 8.33 7.2 62 0.95 1.5
23 IHF80-65-200 2900 30 8.33 55.2 53 8.5 15 2
50 13.9 50 63 10.8 15 2.5
60 16.7 45.2 62 11.9 15 3.2
24 IHF80-65-200 1450 15 4.17 13.5 44 1.25 2.2 2
25 6.94 12.5 57 1.49 2.2 2
30 8.33 11.5 58 1.6 2.2 2.5
25 IHF80-65-250 2900 30 8.33 84 52 13.2 22
50 13.9 80 57 17.3 22 2.4
60 16.7 75 59 20.77 22
26 IHF80-65-250 1450 15 4.17 21 49 1.75 3
25 6.94 20 53 2.27 3 1.4
30 8.33 18.8 56 2.74 3
27 IHF100-80-125 2900 60 16.7 24 67 5.86 11
100 27.8 20 78 7 11 3.2
120 33.3 16.5 74 7.28 11
28 IHF100-80-125 1450 30 8.33 6 64 0.77 1.5
50 13.9 5 75 0.91 1.5 1.8
60 16.7 4 71 0.92 1.5
29 IHF100-80-160 2900 60 16.7 37 60 10.1 15 3.8
100 27.8 32 73 11.9 15 4.3
120 33.3 28 73 12.5 15 5
30 IHF100-80-160 1450 30 8.33 9.25 58 1.3 2.2 3
50 13.9 8 69 1.58 2.2 3.4
60 16.7 7 68 1.68 2.2 3.7
31 IHF100-80-200 2900 60 16.7 56 63 14.5 22 3.4
100 27.8 50 72 18.9 22 3.9
120 33.3 44 71 20.3 22 5.2
32 IHF100-80-200 1450 30 8.33 14 60 1.91 5.5 2.5
50 13.9 12.5 68 2.5 5.5 2.5
60 16.7 11 63 2.85 5.5 3
33 IHF100-80-250 2900 60 16.7 88 57 25.2 37 3
100 27.8 80 68 32 37 3.6
120 33.3 74 67 36.1 37 4.5
34 IHF100-80-250 1450 30 8.33 22 50 3.6 5.5 2.5
50 13.9 20 63 4.3 5.5 2.5
60 16.7 18.5 64 4.7 5.5 3
35 IHF125-100-180 2900 120 33.3 61 68 29.3 45 4.5
200 55.6 50 77 35.4 45 5
240 66.7 41 70 38.3 45 5.8
36 IHF125-100-180 1450 60 16.7 15.25 64 3.89 7.5 2.5
100 27.8 12.5 73 4.66 7.5 2.9
120 33.3 10.25 66 5.08 7.5 3.6
37 IHF150-125-160 2900 200 55.6 32 62 28.1 30
38 IHF150-125-160 1450 100 27.8 8 58 3.8 5.5
39 IHF150-125-160 2900 300 83.3 32 60 43.6 45
40 IHF150-125-160 1450 150 41.7 8 56 5.8 7.5
41 IHF150-125-180 2900 200 55.6 45 62 39.5 45
42 IHF150-125-180 1450 100 27.8 12 60 5.4 7.5
43 IHF150-125-180 1450 200 55.6 12 56 11.7 15
44 IHF150-125-200 2900 200 55.6 50 72 37.8 55
45 IHF150-125-200 1450 100 27.8 12 72 12.1 15

IHF Plastic lined Chemical centrifugal pump mainly used in chemical industry.

Related products: magnetic drive pump.
